System Structure |
Embedded Linux system, ARM chip structure |
|
Chipset |
AK3918E V300 |
|
Resolution |
CMOS 1920x1080, 2MP |
|
Lens |
3.6 MM |
|
View Angle |
80¡ã |
|
Pan-tilt |
Rotates Horizontal: 355¡ã Vertical: Manual 65¡ã |
|
Cruise Setting Point Quantity |
6 |
|
Video Compression Format |
H.265/20FPS |
|
Minimum Illumination: |
0.01Lux@ (F2.0, VGC ON), 0Lux with IR |
|
Electric Shutter |
Auto |
|
Backlight Compensation |
Support |
|
Noise Reduction |
2D/3D |
|
LED Quantity |
4pcs Infrared LED |
|
Network |
WIFI wireless transmission (Support IEEE802.11b/g/n wireless protocol) |
|
Night Vision |
IR-CUT switch automatic, about 5-8 meters (It varies from environment) |
|
Audio |
Built-in microphone and speaker, support two-way audio and real-time transmission. ADPCM audio compression standard, self-adapt to code stream. |
|
Network Protocol |
TCP/IP, UDP, HTTP DDNS, DHCP, FTP, NTP |
|
Alarm |
1, Motion detection and picture push 2, AI Human intrusion Detection (Optional) |
|
Storage |
TF Card (Max 128G) Cloud storage /Cloud disk (Optional) |
|
Power Input |
5V/1.5A |
|
Work Environment |
Working temperature: -10¡æ ~ + 50¡æ Working Humidity: ¡Ü95%RH |
